Voltage instability can damage sensitive equipment, increase maintenance costs and cause expensive downtime. We manufacture single phase and three phase servo voltage stabilizers that provide accurate voltage correction and reliable performance keeping your operations smooth and worry free.
Every stabilizer we manufacture undergoes stringent quality testing and is built to handle Indian voltage conditions. Our solutions not only protect your equipment but also increase productivity, reduce breakdowns and save energy.
| Parameter | Specification |
|---|---|
| Capacity |
1 KVA – 25 KVA (1PH) 3 KVA – 75 KVA (3PH Air Cooled) 75 KVA – 500 KVA (3PH Oil Cooled) |
| Primary Voltage |
200/220V (1PH AC) 380/400/415V (3PH AC) |
| Secondary Voltage |
110/230V (1PH) 220/380/400/415V (3PH) |
| System | Delta / Star, Star / Star |
| Ratio | 1:1 or 2:1 |
| Regulation | ≤ 3.5% |
| Dielectric Strength | 3KV for 60 Sec |
| Insulation Resistance | ≥ 1000 MΩ |
| Leakage Current | < 20 Micro Amps |
| Common Mode Attenuation | 100Db/120Db |
| Operating Temperature | 0°C – 45°C |
| Cooling Type | Natural Air / Forced Air |
| Parameter | Specification |
|---|---|
| KVA Rating | Up to 750 KVA |
| Input Voltage | 415V (Custom voltages available) |
| Output Voltage | 415/200V (Customizable) |
| Configuration | Delta/Star or Zig-Zag |
| Construction | Dry type wound, air cooled, common core, vacuum impregnated |
| Neutral Conductor Rating | 200% |
| Frequency | 50/60Hz |
| Insulation Class | H / 180°C |
| Max Temperature Rise | 125°C |
| Enclosure | M.S. Enclosure as per IP21, Siemens Grey (RAL 7035) |
| Flash Test | 2500V between winding to winding and winding to earth |
| Operating Humidity | 0 – 90% Non Condensing |
Every stabilizer we manufacture undergoes stringent quality testing and is built to handle Indian voltage conditions. Our solutions not only protect your equipment but also increase productivity, reduce breakdowns and save energy.
